EE-SX670A Omron Photoelectric Sensor

Sensing Distance

5 mm (slot width)

Minimum Sensing Object

Opaque, 2 × 0.8 mm

Light Source

Infrared LED

Peak Wavelength

940 nm

Supply Voltage

5–24 V DC ±10%

Current Consumption

12 mA

Output Configuration

NPN Open Collector

Maximum Load Current

100 mA

Residual Voltage

0.8 V max. at 100 mA

Response Frequency

1 kHz minimum, 3 kHz average

Response Time

0.17 ms

Differential Distance

0.025 mm max.

Connection Type

4-pin system connector

Housing Material

PBT plastic

Dimensions (W × H × D)

25.4 × 22.2 × 6.95 mm

Operating Temperature

−25°C to +55°C

Mounting Type

Chassis mounting
