E3Z-R86 Omron Photoelectric Sensor

Model

E3Z-R86

Brand

Omron

Sensor type

Photoelectric sensor

Sensing method

Retro-reflective

Sensing distance

100 mm to 4 m*

Shape

Rectangular / Cuboid

Output type

PNP

Output mode

Light-ON / Dark-ON selectable

Output configuration

PNP open collector

Standard sensing object

Opaque object, 75 mm diameter minimum

Light source

Red LED, 660 nm

Supply voltage

12–24 VDC

Maximum load current

100 mA

Response time

1 ms maximum

Connection

M8, 4-pin connector

Housing material

PBT plastic

Protection rating

IP67

Sensitivity adjustment

Single-turn manual adjustment

Operating temperature

-40°C to +55°C

Dimensions (W × H × D)

10.8 × 31 × 20 mm

Special feature

M.S.R. (Mirror Surface Rejection)

Reflector

Required; ordered separately
