HELIX AUTOMATION SOLUTION
E3Z-B61 Omron Photoelectric Sensor
E3Z-B61 Omron Photoelectric Sensor
Regular price
Rs. 900.00 INR
Regular price
Sale price
Rs. 900.00 INR
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
E3Z-B61 Omron Photoelectric Sensor
| Parameter | Specification |
|---|---|
| Brand | Omron |
| Model | E3Z-B61 |
| Product Type | Photoelectric Sensor |
| Shape | Square / Cuboid |
| Sensing Method | Retro-reflective, without MSR |
| Application | Transparent object detection |
| Sensing Distance | 80 to 500 mm |
| Rated Sensing Distance | 500 mm |
| Reflector | E39-R1S |
| Standard Sensing Object | Opaque object, 75 mm dia. min. |
| Transparent Object | Glass cylinder 15 mm dia., 1.1 mm thickness, 50 mm length |
| Light Source | Red LED |
| Wavelength | 660 nm |
| Output Type | NPN Open Collector |
| Output Mode | Light-ON / Dark-ON selectable |
| Supply Voltage | 12 to 24 VDC ±10% |
| Current Consumption | 30 mA max. |
| Load Voltage | 26.4 VDC max. |
| Load Current | 100 mA max. |
| Response Time | 1 ms max. |
| Sensitivity Adjustment | One-turn adjuster |
| Connection | Pre-wired cable |
| Standard Cable Length | 2 m |
| Optional Cable Length | 0.5 m |
| Housing Material | PBT |
| Lens Material | Modified Polyarylate |
| Protection Rating | IP67 |
| Operating Temperature | -25°C to +55°C |
| Operating Humidity | 35% to 85% RH |
| Dimensions W × H × D | 10.8 × 31 × 20 mm |
| Weight | Approx. 65 g with 2 m cable |
| Indicator | Orange operation indicator, green stability indicator |
